Pneumatic rooj vag valve

Kev tsim kho hnyav, yooj yim thiab txhim khu kev qha rau xyoo ntawm kev ua haujlwm

Ib qho yooj yim installation, tsis tshua muaj txij nkawm

Spout area varied from 100x100 800x800 cm²

Dav siv rau cov khoom noj los yog tawm hauv cov khoom noj, khoom noj, hmoov nplej, tshuaj lom neeg, ntxhia, metallurgy, cement industries.

Daim ntawv thov, adaptability thiab lub hauv paus ntsiab lus ntawm kev thov

Daim ntawv thov

Lub rooj vag pneumatic feem ntau yog siv los tswj kev pub noj thiab tawm ntawm cov khoom.

Adaptability

Cov khoom siv no yog siv dav hauv kev nce qib, hmoov nplej, pub, oilseed thiab zaub mov ua tshuab thiab metallurgical, cement thiab tshuaj lom neeg kev lag luam thiab lwm yam.

Txoj cai ntawm kev thov

Qhov ntom ntom ntawm cov khoom: =0.2-1.8T / m³

Qhov kub ntawm cov khoom: tsis siab tshaj 80 degree

Cov dej noo

Cov ntsiab lus noo noo yog txheeb ze nrog qhov loj me thiab viscosity ntawm cov khoom; Feem ntau cov khoom, uas tsis yog loosed tom qab agglomerated los ntawm kneading los ntawm tes, yuav tsis haum

Technical parameters

Qauv	Lub tog raj kheej qauv	Ua hauj lwm siab (Bar)	Sib nqus hloov	Theoretical zog (N)	Theoretical nro (N)	Muaj peev xwm (T/h)
TZD 1930	DNCB-40-200-PPV-A	0.6-12	SM1-8-K2.5-E	754	633	30
TZM 2430	DNCB-40-250-PPV-A	0.6-12	SM1-8-K2.5-E	754	633	50
TZD 2840	DNCB-50-320-PPV-A	0.6-12	SM1-8-K2.5-E	1178	990	80
TZM 3650	DNCB-50-400-PPV-A	0.6-12	SM1-8-K2.5-E	1178	990	130
TZM 3950	DNCB-50-400-PPV-A	0.6-12	SM1-8-K2.5-E	1178	990	150
TZM 4660	DNCB-63-500-PPV-A	0.6-12	SM1-8-K2.5-E	1870	1682	200
TZM 5470	DNCB-63-550-PPV-A	0.6-12	SM1-8-K2.5-E	1870	1682	300
TZM 63 110	DNCB-80-700-PPV-A	0.6-12	SM1-8-K2.5-E	3016	2721	500

Nco tseg:Qhov saum toj no theoretical thrust thiab theoretical nro yog xam ntawm atmospheric siab ntawm 6 bar.

2(001)

3(001)

Cim npe nrov: tzmq pneumatic rooj vag, Tuam Tshoj, lwm tus neeg, manufacturers, customized, nqe, hais, yuav luv nqi, kev muag khoom, ua nyob rau hauv Suav teb

TZMQ Pneumatic Gate
