SLHY Kab rov tav tov khoom

Hmoov kab rov tav tov khoom

SLHY Kab rov tav ribbon tov khoom hom.

Cov khoom sib xyaw no haum rau kev sib xyaw qhuav, tsis muaj dej ntws hauv cov khoom noj, zaub mov, tshuaj thiab tshuaj lag luam.

Muaj qhov zoo tshaj plaws rotor qauv; txawm sau ntawm lub tov khoom thiab tsis muaj kev tuag ces kaum.

Sib xyaw homogeneity: CV Tsawg dua lossis sib npaug li 7 feem pua, lub sijhawm sib xyaw: 36 min.

Kuj tseem siv tau rau hauv daim ntawv thov rog.

Rov qab cua chute furnished rau sab hauv thiab sab nraud ntsuas ntsuas.

Daim ntawv thov thiab nta

Daim ntawv thov

SLHY kab rov tav ribbon tov khoom yog tsim rau kev sib xyaw cov ntaub ntawv farinaceous pub mills, ua kom muaj kev faib tawm ntawm cov khoom xyaw hauv cov mash sib tov, thiab ua kom zoo ntawm cov mis pub.

Nta

SLHY tov khoom yog kab rov tav batch tov khoom, uas muaj cov nram qab no nta:

- Cov qauv tshiab ntawm lub rotor, zoo sib xyaw homogeneity thiab dawb ntawm qhov chaw tuag ntawm kev sib xyaw ua haujlwm;

- Kho qhov tshem tawm ntawm rotor thiab casing, thiab lub qhov rooj tawm hauv qab tag nrho nrog cov seem me me;

- Ob chav phab ntsa tsim rau ob qho kawg ntawm lub tshuab lub cev, zam cov khoom xau ntawm ob qho kawg ntawm tus ncej;

- Pneumatic hom (hom hluav taws xob kuj muaj) tso tawm rooj vag nrog kev ua tau zoo dua thiab txhim khu kev qha thiab kev sib khi zoo dua;

- Ua- hauv cov kav dej siv roj; tsim nyog tus qauv, zoo li zoo raws li ib qho yooj yim kho thiab txij nkawm.

Main qauv

Cov khoom sib xyaw muaj xws li lub rotor, lub tshuab lub cev, lub qhov rooj tawm, lub tshuab tso tawm thiab lub raj xa dej, thiab lwm yam.

Rotor

Lub rotor muaj cov ribbons, ib tug ncej, ib ncig lub nplhaib thiab ib tug txhawb nqa thiab lwm yam. Cov ribbons muab faib ua ib tug kauv sab hauv thiab ib tug kauv sab nraud, uas nyob rau hauv sab laug- tes thiab sab xis - tes tig raws. Thaum lub rotor tig, sab laug - tes ribbon thawb cov ntaub ntawv mus rau pem hauv ntej ntawm ib kawg mus rau lwm qhov, thaum sab xis - tes ribbon thawb cov khoom txav mus rau hauv txoj kev rov qab. Los ntawm xws li nruam stirring thiab convection ua, cov ntaub ntawv tau sib tov tusyees. Scrapers yog welded rau lub zog txhawb nqa ntawm sab nraud ribbon ntawm ob qhov kawg ntawm lub rotor, qhov twg nws nyob ze rau ntawm phab ntsa ntawm lub tshuab lub cev. Nrog rau cov scrapers no cov ntaub ntawv nyob rau hauv plaub fab ntawm lub trough yuav txaus sib tov.

Technical parameters
